Quick Details

  • Condition: New
  • CNC or Not: CNC
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: SUDIAO (SD)
  • Model Number: SD--1313
  • Voltage: 380V
  • Weight: 1600kg
  • Certification: CE
  • Warranty: ONE YEAR
  • After-sales Service Provided: Engineers available to service machinery overseas
  • X axis working travel: 300mm*4
  • Y axis working travel: 1300mm
  • Z axis working travel: 200mm
  • spindle: 4 pcs 2.2kw water cooling spindle
  • square orbit: Taiwan HIWIN or PMI
  • Inverter: Sunfar (delta optional)
  • driver: Leadshine brand(yaskawa optional)
  • control system: Weihong Ncstudio

Packaging & Delivery

Packaging Details film and wooden case
Delivery Time 7-15 days

Specifications

1. WEIHONG Ncstudio
2. water cooling spindle
3.Leadshine ME872-SD
4.CE



  SD-1313 cnc carving machine with 4 heads for screen, wave plate

Product Description



All machine heads can process at the same time, can also work alone,many times increasing in efficiency . Can also control the machine heads Independently, can use only one head to process and make increasing the working area .

Adopt German double-nut ball screws ,imported square guide rail ,the adoption of the break point memory, Guarantee in the accident (power off )or the next day can process.

Gantry movement, long time use no distortion, the more precise positioning accuracy .

Large cutting power not only to elaborately carved a jagged, also smooth clear bottom .

Increase the efficiency when doing the complicated graph; good coherence and high quality when batch processing; good stability with the long time working and low error ratio .

Well compatibility in software;all kind of 3D and JD caving software .

Can make the quantity of the heads and the working area for the machine as per customer's request.





  Technical parameters:





ModelSD-1313
Working travelX axis300mm*4
Y axis1300mm
Z axis200mm
Table structureAluminum
OrbitHIWIN or PMI square orbit
Transmission typeX,Y helical gear rack, Z Taiwan TBI ball screw
Working accuracy±0.05
Repositioning accuracy±0.05
Max air move speed30000mm/min
Max working speed15000mm/min
Spindle parametersType of coolingWater cooling
Power2.2KW*4
Speed0-24000r/min
Inverter2.2KW *4 Sunfar Inverter
Drive systemLeadshine ME872-SD
Command codeG code
Control systemWEIHONG Ncstudio
Oiling systemManual
Working voltageAC380V/3PH/50HZ, AC220V/50HZ







  Sample:







Packaging & Shipping



1. Outside package: Sandard export wooden cases

2. Inner package: Stretch film



Delivery time : after sure down payment , within 10 days arrange shipping



Our Services



Our after-sales service:

1. One year quality guaranty, the machine with main parts(excluding the consumables) shall be changed

free of charge when problems happened during the warranty period.

2. Lifetime maintenance free of charge.

3. Free training course at our plant.

4. We will provide the consumable parts at an agency price when you need replacement.

5.  12 hours on line service each day, free technical support.

6. Machine has been adjusted before delivery , operation disk was included.

7. Our engineer supply oversea teaching service.











FAQ



  1: how about the Max working area you need ?



 2: what material you work on ?



3: what work you do , engraving , cutting ?



4 : what type after sale service you need we provide ?
